Key Specs
- Platform Height: 19 ft / 5.79 m
- Platform Capacity: 606 lb / 274.88 kg
- Machine Width: 2 ft 8 in. / 0.81 m
- Drive Speed - Platform Lowered: 4 mph / 6.44 km/h
Key Features
- Improved Cost of Ownership: This model sets a new industry benchmark with almost no maintenance, with a new diagnostic and analyzer tool that can be used on any smart device
- Longer Battery Life: Class-leading, single lithium ion battery lasts the life of the machine
- Faster Charging: Quick charge in five minutes for 100 ft of drive plus enough torque for loading
|
|
| Length |
5 ft 9 in. / 1.74 m |
| Width |
2 ft 8 in. / 0.81 m |
| Height |
6 ft 11 in. / 2.11 m
6 ft 6 in. / 1.99 m (Rails Folded) |
| Weight |
3,450 lb |
| Turning Radius |
5 ft 6 in. / 1.68 m Outside
0 Inside |
| Platform |
25.4 x 62.7 in |
| Brakes |
Multi-Disc Friction |
| Max Travel Speed |
4 mph / 6.44 km/h |
| Tires |
12.5” x 4” (Non-Marking) |
| Gradeability |
25% |
| Capacity |
606 lb / 274.88 kg |
| Travel Speed - Forward |
4 mph / 6.44 km/h |
| Platform Height |
19 ft / 5.79 m |
| Raise/Lower Time |
24/26 seconds |
- Improved Cost of Ownership: This model sets a new industry benchmark with almost no maintenance, with a new diagnostic and analyzer tool that can be used on any smart device
- Longer Battery Life: Class-leading, single lithium ion battery lasts the life of the machine
- Faster Charging: Quick charge in five minutes for 100 ft of drive plus enough torque for loading
- Smoother Operation: Efficient AC drive motors provide 4 mph stowed drive speed, while independent wheel motor control reduces tire wear and limits damage to sensitive flooring
- Increased Efficiency: Fully electric and highly efficient for zero emissions and zero leaks
- ANSI A92.20 Compliance: Load sensing system, self-closing gate and QuikFold rail system
- Zero leak points
- QuikFold Rails
- USB Charger & Phone Holder
- CAN-Enabled Charger
- Load Sensing System
- Self-Closing Gate
- Proportional Controls
- AC Electric Drive
- Battery Condition Indicator
- AC Receptacle in Platform
- All Motion Alarm
- 650W CAN-Charger (3.5hr full charge)
- Horn
- Hourmeter
- Tilt Alarm and Light
- Lanyard Attach Points
- Movable, Removable Platform Control
- Nickel Plated Pins
- Lubrication Free Scissor Arm Bushings
- Scissor Maintenance Prop
- Active Pothole Protection System
- Lifting and Tie Down Points
- Fork Lift Pockets
- Manual Descent Cable
- Foot-Actuated Deck Extension
- Steel Drop-Down Doors
- Variable Tilt Visual Zone Indicator
- Diamond Tread Steel Deck
- Greaseless Kingpin Joints
- Dynamic Braking
- Removable Ladder
- Electric Brake Release
- Quick Charge - 5 min = 100ft + on Truck
- JLG Mobile Control
- Drive Motor Covers
- Next Gen Analyzer Used via Smart Device
• Coiled Platform Control Box Cable
• Anti-Vandalism PKG
• 900W Inverter
• White Noise Alarm
• ClearSky™
• QuikAccess Platform
• LCD Platform Control Box
• Dual LED Flashing Amber Beacon
• Flashing Amber Beacon
• 900W CAN-Charger
