Articulated combi roller with vibratory drum
- Diesel engine with high power and low sound level
- Pressure sprinkler system with 2 water pumps; spray nozzles visible from driver seat
- Driver seat including steering wheel and instrument panel can be rotated and moved
- Clear view of drum surface, its outer edge and working environment
- Crab steering to increase working width
- Hydrostatic all-wheel drive for excellent hill climbing ability
|
|
| Length |
189 in. (4,800 mm) |
| Width |
70.9 in. (1,800 mm) |
| Height |
117.3 in. (2,980 mm) |
| Weight |
19,227.6lbs |
| Wheelbase |
141.7 in. (3,600 mm) |
| Inside Turning Radius |
232.3 in. (5,900 mm) |
| Steering Angle |
+/-30° |
| Drum |
Front: Smooth/Split |
| Engine Make |
Deutz |
| Engine Model |
TCD 3.6 L4 |
| Engine Type |
4-cylinder |
| Horsepower |
113.9 hp (85 kW) @ 2,300 rpm |
| Fuel Tank Capacity |
45.7 gal. (173 l) |
| Drum Width |
66.14 in. (1,680 mm) |
| Drum Diameter |
47.2 in. (1,200 mm) |
| Nominal Amplitude |
Front I / II: 0.024 / 0.013 in. (0.62 / 0.34 mm) |
| Vibration Frequency |
Front I / II: 2,520 / 3,000 vpm (42 / 50 Hz) |
| Centrigual Force Range |
Front I / II: 16,875 / 13,500 lbs. (75 / 60 kN) |
| Travel Speed - Forward |
0 - 7.5 mph (0 - 12 km/h) |
| Water Tank Capacity |
220 gal. (834 l) |
| Application |
Asphalt |
| Static Linear Drum Load |
154.2 lbs./in. (27.5 kg/cm) front |
| Operating Weight |
19,050 lbs. (8,641 kg) with ROPS |
| Axle Load |
10,192 lbs. (4,623 kg) front
8,858 lbs. (4,018 kg) rear |
- Description: Tandem roller with vibrating roller drum and set of tires
- Exhaust emissions Category: EU Stage IV/EPA Tier 4
- Total Length: 192.9”
- Width: 70.9”
- Total Height: 118.5”
- Drum Width: 66.1”
- Height, loading, min: 87.6”
- 12 V outlet
- Central water drain
- Water tank front and rear, can be filled from both sides
- Water filtering (triple)
- Track offset, hydraulic
- Spray system with spray bars front and rear
- Vibration-isolated operator’s platform
- Speed preselect
- Speed-controlled water sprinkling system
- Operator’s platform with entry from both sides
- ECO mode
- Pressure water sprinkling with interval switch
- Operating concept Easy Drive
- Foldable scraper
- 2 large working and rear view mirrors
- Heating
- Coming home lighting
- Rotating beacon
- Working light
- Back-up alarm
- Track offset display
- HAMM Temperature Meter (HTM)
- Automatic engine-off function
- Edge pressing and cutting equipment
- Protective roof
- HCQ navigator
- Steering column with comfort exit and tiltable dashboard
- Multifunction armrest, right, foldable
