Upper Carriage: Large capacity operator's compartment
250,840 lbs. (113,780 kg)
Max Tip Height
229 ft 8 in.
228 hp (168 kW)
Max Travel Speed
0 - 1.55 mph (0 - 2.5 km/h)
Fuel Tank Capacity
143 gal. (540 l)
Load sensing / LUDV hydraulic system with hydraulic and pilot controlled work functions, and load limit sensing control; 1 variable-displacement piston pump with a 3 section gear pump; max. output of 132 gpm (500 lpm); 4,786 psi (330 bar); 297 gal. (1,125 l) steel hydraulic reservoir with sight level gauge; high performance 3 micron filtration system
73,458 lbs. (33,320 kg) total, 5 pieces, hydraulically installed and removed
26 ft. 3 in. (8 m) offsettable, solid, 1-piece swingaway
4-section, full power, sequenced-synchronized, telescopic boom
Max Boom Length
131 ft. 11 in. (40.2 m)
2-speed driven via axial piston hydraulic motor with compact planetary gear, spring loaded disc brake; grooved drum with drum rotation indicator for both hoists that is located in the joystick controls
(2) 12V maintenance free batteries; 24V; battery disconnect switch
Lighting package includes 2 halogen lights integrated into the front side of the cab roof and 1 LED headlight on the upper carriage, right side
