Virnig V70 Open Front Rotary Brush Cutter

New Virnig Brush Cutter

New Virnig V70 Open Front Rotary Brush Cutter for Sale

Top‑tier four blade cutter featuring a massive flywheel to power through hardwood, and premium features for unmatched performance and longevity.

Models

  • PBC72-O
  • PBC78-O
  • PBC84-O


Dimensions
Weight PBC72-O: 2,060 lbs.
PBC78-O: 2,220 lbs.
PBC84-O: 2,330 lbs.
Overall Width PBC72-O: 78”
PBC78-O: 84”
PBC84-O: 90”
Overall Height 27.4”
Deck Height 7.2”
Cutting Width PBC72-O: 72”
PBC78-O: 78”
PBC84-O: 84”
Overall Depth PBC72-O: 81.8”
PBC78-O: 87.8”
PBC84-O: 93.8”
Push Bar Height 20.4 (from ground)
Deck Thickness 0.25’ (top/side)
Flywheel Weight PBC72-O: 560 lbs.
PBC78-O: 625 lbs.
PBC84-O: 635 lbs.
Engine
Recommended Flow Rate 20-25 GPM Standard Flow
25-35, 39-45 GPM High Flow
35-50 GPM High Pressure
Hydraulic
Operating Pressure 3500 PSI Standard Flow
4100 PSI High Flow
4500 PSI High Pressure
Operational
Cutting Capacity Diameter 10”
Operating Capacity Greater than 2800 lbs.
Cut Height 2.2”
Blade Tip Speed Standard Flow Models 20/25 GPM
--PBC72-25-O: 11,030/13,780 FPM
--PBC78-25-O: 11,950/14,930 FPM
--PBC84-25-O: 12,870/16,070 FPM
Standard Flow Models 25/30 GPM
--PBC72-30-O: 13,780/16,530 FPM
--PBC78-30-O: 14,930/17,910 FPM
--PBC84-30-O: 16,070/19,290 FPM
High Flow Models 30/35 GPM
--PBC72-35-O: 13,195/15,400 FPM
--PBC78-35-O: 14,295/16,685 FPM
960 FPM --PBC84-35-O: 15,390/17,
High Flow Models 39/45 GPM
--PBC72-4055 FPM 5-O: 11,325/13,
--PBC78-45-O: 12,2145 FPM 70/14,
--PBC84-45-O: 13,220/15,235 FPM
HP Cutter Models 35/50 GPM
--PBC72-50-O: 12,425/17,755 FPM
--PBC78-50-O: 13,455/19,235 FPM
--PBC84-50-O: 14,495/20,720 FPM
Recommended Loader Capacity Greater than 2200 pounds
Number of Teeth PBC72-O: 20 (optional)
PBC78-O & PBC84-O: 24 (optional)
  • DESIGNED TO KEEP YOU RUNNING WITH DIRECT DRIVE EATON® GEROLER & SAI® PISTON MOTOR OPTIONS, MOTOR GUARD, SPINDLE GUARD, PRESSURE RELIEF VALVES & SPINDLE VENT
  • MASSIVE 7/8″ THICK FLYWHEEL GENERATES UP TO 28,000 MORE FOOT-POUNDS OF ROTATIONAL ENERGY THAN V60 IBC-O TO PROCESS TOUGH MATERIAL FASTER. ROUND SHAPE GLANCES OFF OBJECTS FOR SMOOTHER CUTTING WITH LESS DRIVETRAIN SHOCK & STRESS
  • 4 BLADES DELIVER MORE CUTS PER REVOLUTION FOR SMOOTHER CUTTING & ARE REVERSIBLE FOR 2X THE LIFE
  • UP TO 52″ OF MACHINE-SHARPENED BLADE EDGE, 2X MORE THAN MANY 4-BLADE CUTTERS, TO CUT LIKE AXES FOR PROCESSING MATERIAL & DELIVERING A MANICURED FINISH
  • 9 3/8″ WIDE BY 1/4″ THICK DECK CHANNELS PROVIDE INDUSTRY LEADING STRENGTH WHILE SHEDDING MATERIAL FASTER & MAKING CLEANING EASY
  • REPLACEABLE DECK RUNNERS & FRONT SKID SHOES WHICH ARE DESIGNED TO CUT GROUND LEVEL & HELP GLIDE OVER ROUGH TERRAIN
  • ANGLED REAR DECK CORNERS IMPROVE MATERIAL FLOW & TAPERED REAR DECK RUNNERS REDUCE GROUND DISTURBANCE
  • HYDRAULIC BRAKING STOPS FLYWHEEL WITHIN 25 SECONDS & LIFT LIMIT CHAIN PROTECTS OPERATOR
  • CARBIDE TEETH: Grind stumps and mulch material for a better finish.
  • PRESSURE GAUGE: Monitor hydraulic operating pressure for max productivity. Helps utilize full flywheel inertia and maintain high performance without going into relief..

*Price, if shown, is Manufacturer's Suggested Retail Price (MSRP) and does not include government fees, taxes, dealer freight/preparation, dealer document preparation charges or any finance charges (if applicable). MSRP and/or final actual sales price will vary depending on options or accessories selected.

New Equipment Sales only available in assigned territories where Kirby-Smith Machinery, Inc. is a licensed distributor. Not all manufacturer's brands available at each location. Please contact your local Kirby-Smith branch if you have questions regarding availability.

View Brochure

Main Technical Specifications
MAKE Virnig
MODEL V70 Open Front Rotary Brush Cutter

Want to rent it?

Do you want to know if renting makes more economical sense?
Call us and find out today.

Virnig V70 Open Front Rotary Brush Cutter

print
6715 W. Reno
Oklahoma City, OK 73127 Phone: 888.861.0219
www.kirby-smith.com
CUSTOMER
DATE
PRICE
SALESPERSON

New Virnig V70 Open Front Rotary Brush Cutter for Sale

Top‑tier four blade cutter featuring a massive flywheel to power through hardwood, and premium features for unmatched performance and longevity.

Models

  • PBC72-O
  • PBC78-O
  • PBC84-O


GENERAL INFORMATION
Manufacturer
Virnig
Model Year
Model
V70 Open Front Rotary Brush Cutter
Condition
NEW
Dimensions
Weight
PBC72-O: 2,060 lbs. PBC78-O: 2,220 lbs. PBC84-O: 2,330 lbs.
Overall Width
PBC72-O: 78” PBC78-O: 84” PBC84-O: 90”
Overall Height
27.4”
Deck Height
7.2”
Cutting Width
PBC72-O: 72” PBC78-O: 78” PBC84-O: 84”
Overall Depth
PBC72-O: 81.8” PBC78-O: 87.8” PBC84-O: 93.8”
Push Bar Height
20.4 (from ground)
Deck Thickness
0.25’ (top/side)
Flywheel Weight
PBC72-O: 560 lbs. PBC78-O: 625 lbs. PBC84-O: 635 lbs.
Engine
Recommended Flow Rate
20-25 GPM Standard Flow 25-35, 39-45 GPM High Flow 35-50 GPM High Pressure
Hydraulic
Operating Pressure
3500 PSI Standard Flow 4100 PSI High Flow 4500 PSI High Pressure
Operational
Cutting Capacity Diameter
10”
Operating Capacity
Greater than 2800 lbs.
Cut Height
2.2”
Blade Tip Speed
Standard Flow Models 20/25 GPM --PBC72-25-O: 11,030/13,780 FPM --PBC78-25-O: 11,950/14,930 FPM --PBC84-25-O: 12,870/16,070 FPM Standard Flow Models 25/30 GPM --PBC72-30-O: 13,780/16,530 FPM --PBC78-30-O: 14,930/17,910 FPM --PBC84-30-O: 16,070/19,290 FPM High Flow Models 30/35 GPM --PBC72-35-O: 13,195/15,400 FPM --PBC78-35-O: 14,295/16,685 FPM 960 FPM --PBC84-35-O: 15,390/17, High Flow Models 39/45 GPM --PBC72-4055 FPM 5-O: 11,325/13, --PBC78-45-O: 12,2145 FPM 70/14, --PBC84-45-O: 13,220/15,235 FPM HP Cutter Models 35/50 GPM --PBC72-50-O: 12,425/17,755 FPM --PBC78-50-O: 13,455/19,235 FPM --PBC84-50-O: 14,495/20,720 FPM
Recommended Loader Capacity
Greater than 2200 pounds
Number of Teeth
PBC72-O: 20 (optional) PBC78-O & PBC84-O: 24 (optional)
