Link-Belt 4040B RB

New Excavator for Sale

New Link-Belt 4040B RB Excavator for Sale

The enhanced 40B Series showcases improved durability, productivity, serviceability, and overall safety.
Dimensions
Length 34’9.3”
Width 11’11.3”
Height 12’10.3”
Operating Weight 87,400 lbs.
Fuel Tank Capacity 216 Gallons
Maximum Reach Ground 27’2.4”
Vertical Wall Depth 14’8.4” (High-Narrow Undercarriage)
15’5.6” (High-Wide Undercarriage Standard Lift Position)
14’5.6” (High-Wide Undercarriage High-Lift Position)
Engine
Engine Make Isuzu
Engine Model AQ-6HK1X
Horsepower 207 HP
Displacement 475 cu in
Torque 626 lbf-ft.
Cooling System Capacity 9.5 Gallons
DEF Tank Capacity 31.7 Gallons
Travel Speed 1.5-2.5 MPH
Drivetrain
Starter 24V-5.0kW
Gradeability 70% (35°)
Drawbar Pull 69,600 lbf
Alternator 90 amp
Track Rollers 8 per side
Ground Pressure 9.43 PSI
Carrier Rollers 2 per side
Hydraulic
Hydraulic Tank Capacity 39 Gallons (Sump)
Hydraulic System 2 variable displacement axial piston pumps with regulating system
Hydraulic Cylinders NO. of Cylinders – Bore X Rod Diameter X Stroke
Boom: 2 – 5.51” X 3.74” X 53.90”
Arm: 1 – 5.91” X 4.13” X 61.77”
Bucket: 1 – 5.31” X 3.54” X 42.44”
Oil Capacity 10.8 Gallons
Hydraulic System Capacity 79 Gallons
Max Oil Flow Main Pumps: 2 x 64.2 GPM
Pilot Pump (1 Gear Pump): 7.1 GPM
Aux. Pump (1 Gear Pump): 9.7 GPM
Working Circuit Pressure Main Pumps: Working Circuit Pressure: Boom/Arm/Bucket-4970 PSI; Swing Circuit-4410 PSI; Travel Circuit-4970 PSI
Pilot Pump (1 Gear Pump): 570 PSI
Aux. Pump (1 Gear Pump): 2990 PSI
Operational
Dig Depth 22’6.9” (High-Narrow Undercarriage Standard Lift Position)
22’4.1” (High-Wide Undercarriage Standard Lift Position)
18’8.4” (High-Narrow Undercarriage High-Lift Position)
18’5.7” (High-Wide Undercarriage High-Lift Position)
22’.6” (High-Narrow Undercarriage Standard Lift Position – Level Bottom)
22’4.1” (High-Wide Undercarriage Standard Lift Position – Level Bottom)
18’2.1” (High-Narrow Undercarriage High-Lift Position – Level Bottom)
17’11.4” (High-Wide Undercarriage High-Lift Position – Level Bottom)
Dig Height 33’9.5” (High-Narrow Undercarriage Standard Lift Position)
34’0.3” (High-Wide Undercarriage Standard Lift Position)
38’2.7” (High-Narrow Undercarriage High-Lift Position)
38’5.4” (High-Wide Undercarriage High-Lift Position)
Dump Height 23’11.8” (High-Narrow Undercarriage Standard Lift Position)
24’2.6” (High-Wide Undercarriage Standard Lift Position)
27’11.4” (High-Narrow Undercarriage High-Lift Position)
28’2.2” (High-Wide Undercarriage High-Lift Position)
Maximum Reach 34’4.2” (High-Narrow Undercarriage)
34’3.4” (High-Wide Undercarriage)
Swing Torque 82,700 lbf-ft.
Swing Speed 0-8.5 RPM
Track Link Pitch 8.50”
Shoes 48 per side
Shoe Width 27.5”
Battery
Voltage 24V
