Link-Belt 300 X4S

New Link-Belt Excavator for Sale

New Link-Belt 300 X4S Excavator for Sale

Looking to boost your earth-moving productivity, without added fuel costs? The adaptability and maximum performance of the X4S line give you the power to tackle tough jobs.

  • Newly designed, full-size spacious cab
  • 10” machine monitor enhances operator experience
  • Superior fuel efficiency
Dimensions
Width 11’2”
Operating Weight 67,700 lbs.
Fuel Tank Capacity 126 Gallons
Maximum Reach Ground 32’11”-36’0”
Engine
Engine Make Isuzu
Engine Model AQ-6HK1X
Engine Type Final Tier 4 turbocharged diesel engine
Net Horsepower 253 HP
Displacement 475 cu in
Torque 711 lbf-ft
DEF Tank Capacity 22 Gallons
Travel Speed 2.0-3.3 mph
Drivetrain
Starter 24 V – 5.06 kW
Gradeability 70% (35°)
Drawbar Pull 55,500 lbf
Alternator 90 amp
Track Rollers 8 per side
Ground Pressure 6.4 PSI
Carrier Rollers 2 per side
Hydraulic
Pump Output 2 x 67.6 gpm
Hydraulic Tank Capacity 46 Gallons
Hydraulic Cylinders Number – Bore x Stroke:
Boom: 2 – 5.5” x 53.9”
Arm: 5.9” x 65.0”
Bucket: 5.3” x 42.4”
Relief Valve Setting Boom Up/Arm/Bucket: 4,970 PSI
In Power Boost: 5,410 PSI
Hydraulic System Capacity 83 Gallons
Travel Circuit 4,970 PSI
Swing Circuit 4,410 PSI
Pilot Pump Maximum Flow 7.5 gpm
Operational
Dig Depth 21’7”-24’10”
Dig Height 32’7”-34’1”
Bucket Digging Force 42,780 lbf
Dump Height 22’9”-24’3”
Maximum Reach 33’6”-36’7”
Swing Torque 67,900 lbf-ft
Swing Speed 10.0 RPM
Track Link Pitch 8”
Shoes 50 per side
Shoe Width 31.5”
Tail Swing 10’10”
Bucket Rotation 176°
Arm Force 31,380 lbf
Boom
Boom 20’2”
Battery
Voltage 24 V
  • RemoteCARE
    • The Link-Belt 300 X4S comes standard with a new dualband modem to improve RemoteCARE communication and functionality with greater range and real-time data capabilities – providing 24/7 remote monitoring with zero subscription charges or fees.
  • Standard Warranty
    • The Link-Belt 300 X4S hydraulic excavator is fully backed by a 5-year/5,000-hour full machine warranty and a 5-year/10,000 Structural Warranty.
  • CAB
    • 270° WAVES+ 3-Camera System
    • Cab Sun Visor (Front)
    • CAB Head Guard (FOPS Level 2)
    • Front Guard (Mesh)
    • Front Guard (BAR - OPG Level 1)
    • Front Guard (BAR - OPG Level 2)
    • LED Lights for WAVES Cameras (4)
    • Rain Deflector
    • Vandal Cover (Front Window)
  • ENGINE
    • Reversible Cooling Fan
  • HYDRAULICS
    • Hose Burst Check Valve
  • AUXILIARY HYDRAULIC OPTIONS
    • Multi-Function Aux. w/ in-cab Pressure Settings and Proportional Joystick
    • Combination Aux. w/ in-cab Pressure Settings and Proportional Joysticks
  • UNDERCARRIAGE
    • 600 mm shoes (23.6 in) 3-Bar Steel
    • 700 mm shoes (27.5 in) 3-Bar Steel
    • Triple Track Guards
  • ATTACHMENT
    • 10’ 5” (3.18 m) HD Arm
    • 12’ 0” (3.66 m) HD Arm
    • 8’ 8” (2.65 m) HD Arm
