Komatsu TN230D

New Komatsu Swing Machine

New Komatsu TN230D Swing Machine Forestry for Sale

Tackle tough forestry jobs with confidence using Komatsu wheeled harvesters, forwarders, log loaders, swing machines, felling heads and harvesting heads. Forestry work is often in the most rugged terrain and brutal conditions — and Komatsu forestry equipment is engineered for the task.

A swing machine purpose-built for productivity

We developed the TN230D from the ground up with one goal — merging quality components with the latest technology. Your forestry operation will benefit from increased horsepower and faster cycle times.* Operators will appreciate the wide views, rear-entry cab design and large cooling package.

  • Excellent visibility — elevated cabin with large windows, overhead skylight and front-view camera
  • Dual service platforms — the first in this machine class segment to offer this feature
  • Improved service access capabilities to components* such as the engine and hydraulic main valve

*Increased power, faster cycle times and improved service access compared to the PC210LL-10 Komatsu truck loader (a similar class machine).



Features and Benefits

  • Purpose-built forestry machine: Total ground-up design for tough forestry jobs. Features and improvements were engineered by integrating customer feedback.
  • Exceptional serviceability: Electrically actuated left and right-side service platforms with repositioning of the main valve to allow better access. Also allows better entry to the engine through the large electronically powered engine hood.
  • User-friendly operator accessibility: Swing machine is designed to drive zero harm when the operator is entering the cab. Rear entry cab includes walkways and safety railings.
  • Designed for reliability and durability: Built with proven, high-quality components. Hydraulic system, powertrain, control valve and interior components are designed and manufactured in-house to help ensure performance and quality control.
  • Excellent operator visibility: Elevated cabin with large windows and front view camera to optimize operator visibility. Large overhead skylight also allows better visibility and improves the operator experience.
  • Power Max: Useful when your operators need a boost of power for forestry challenges. Power Max momentarily increases the engine horsepower and hydraulic flow to help accomplish a tough task.
Body
Frame Type X-frame (Center)
Number of Carrier Rollers 2 (each side)
Number of Shoes 51 (each side)
Number of Track Rollers 10 (each side)
Seal of Track Sealed Track
Steering Control Two levers with pedals
Dimensions
Width 11’6”
Height 10’6” (top of engine hood)
11’5” (top of handrill)
Ground Clearance 4’6” (revo frame)
2’4” (track frame)
Overall Width 10’11”
Overall Height 16’4” (to top of cab)
11’5” (for transport (riser tilt position – grouser height included))
Operating Weight 73,500 lbs.
Transport Ground Length 41’6”
Engine
Engine Make Komatsu
Engine Model SAA6D170E-3
Engine Type Water-cooled, 4-cycle, direct injection
Horsepower 197 HP
Bore x Stroke 4.21” x 4.88”
Fuel Tank Capacity 105.7 Gallons
Governor All-speed control, electronic
Piston Displacement 408 in³
Fan Drive Type Mechanical (radiator cooling)
DEF Tank Capacity 6.1 Gallons
Coolant Capacity 9.4 Gallons
Engine Capacity 6.1 Gallons
Final Drive Capacity 1.3 Gallons (each side)
Drivetrain
Track Length 15’5”
12’7” (on ground)
Ground Pressure 8.1 PSI
Grouser Height 0’1”
Track Adjuster Hydraulic
Operational
Gradeability 35 deg
Maximum Reach 35’5” (at ground level)
36’
Tail Swing Radius 10’3”
Drawbar Pull 47,659 lbf.
Swing Torque 58,334 ft-lbs.
Swing Speed 11.7 RPM
Track Gauge 8’7”
Swing Reduction Planetary Gear
Swing Circle Lubrication Grease-bathed
Swing Brake Service: Hydraulic Lock
Holding Brake/Swing Lock: Mechanical Disc Brake
Drive Method Hydrostatic
  • Engine and related components
    • Engine, Komatsu SAA6D107E-3, Tier 4 final
    • Gross HP (J1995): 213 HP
    • Net HP (J1349): 197 HP
    • Komatsu Diesel Particulate Filter (KDPF)
    • Selective Catalytic Reduction (SCR)
    • After-cooled, turbocharged direct injection
    • Air cleaner, double element
    • Fuel pre-filter, 10 micron
  • Cooling system
    • Radiator/oil cooler (8.5 fins per inch)
    • Variable pitch, automatic reversing fan
  • Electrical system
    • Alternator (90 amps / 24V)
    • Large capacity batteries (2 x 12V)
    • Starter motor (5.5 kW / 24 V x1)
    • Working Lights: 12 LED Lights (13 tree deflector guard)
    • Engine shutdown secondary switch
    • Battery disconnect switch
    • 24 V-12 converter, 30 A
  • Undercarriage
    • High/wide forestry undercarriage
    • Heavy-duty revolving frame
    • 28” double grouser shoes
    • Track rollers, HD 10/side
    • Carrier rollers (2), track type/side
    • Heavy-duty recoil spring
    • Heavy-duty tow hooks
    • Track guard full-length ski-type
  • Guards and covers
    • Dustproof net for radiator and oil cooler
    • Heavy-duty forestry guards
    • Heavy-duty doors, .24” thick
    • Heavy-duty under guard .24” thick
    • Pump/engine partition cover
    • Forestry debris screens
    • Grip strut walkways
    • Boom cylinder guard
    • Brush deflector guard
  • Operating equipment
    • Komatsu forestry cab with 48” fixed riser
    • 1.25” polycarbonate front window
    • ROPS/OPS/TOPS/FOPS/WCB/Oregon OSHA certified
    • Automatic HVAC
    • Monitor panel, LCD, high-resolution color
    • Equipment management monitoring system (EMMS)
    • Seat, high back, air suspension, heated/cooled
    • Radio with Bluetooth
    • Adjustable arm rests
    • Cup holder
    • 3" lap belt
  • Work equipment
    • Forestry boom 20.2'
    • Forestry arm 11'5"
    • Truck loading-specific piping package
    • Case drain filter, high pressure filtration
    • Boom and arm holding valve
  • Hydraulic controls
    • Axial piston swing motor (1)
    • Axial piston travel motors (2)
    • Variable capacity piston pumps (2)
    • Closed Center Load Sensing Pumps (CCLS)
    • Hydraulic pump high-pressure discharge filters
    • PC240-class swing bearing and swing machinery
    • Engine/hydraulic overheat prevention system
  • Drive and brake system
    • PC240-class final drives
    • 3-speed travel with auto shift
  • Other equipment
    • Komtrax Level 5.0 monitoring system
    • Rear view monitoring camera
    • Electronically fold-down service platforms (2)
    • Tie-off point for service
  • Guards and covers
    • Tree guard and toolbox protector
  • Operator environment
    • Top, front, rear and side sunshades
  • Other equipment
    • 4-point operator's harness

*Price, if shown, is Manufacturer's Suggested Retail Price (MSRP) and does not include government fees, taxes, dealer freight/preparation, dealer document preparation charges or any finance charges (if applicable). MSRP and/or final actual sales price will vary depending on options or accessories selected.
